Epson EH-TW7400

KEY FEATURES & BENEFITS

  • 4K PRO-UHD for crisp, clear images: 4K-enhanced, Full HD, UHD BD and HDR support
  • Smooth, fast-moving action: Frame interpolation and Detail Enhancement
  • Watch a movie a day for 7 years: 5,000 hours lamp life in Eco mode
  • Fully motorised optics: Powered zoom, focus and lens shift
  • Wide lens shift: Vertical ±96.3% and horizontal ±47.1%
Categories: , SKU: Epson-EH-TW7400
  • Features
  • Specifications
  • Downloads
  • Video

Amazing picture quality for the ultimate home cinema experience

Enjoy the big screen experience at home with access to the latest 4K content with this affordable home cinema projector featuring sharp images, and an incredibly high contrast ratio, all with great connectivity and easy set up.

Size matters

Make your home centre stage for all the action with Epson’s home projectors. Transform the everyday, whether you’re catching your favourite sports, watching a classic movie, streaming a box set or playing the latest game. You can capture everyone’s attention with an impressive 300” display and bring family and friends together to experience those memorable moments.

Epson 4K PRO-UHD

Delivers an amazing 4K UHD experience with advanced pixel-shifting, resolution-enhancement technology.

Epson 4K PRO-UHD is not just a resolution specification but rather encompasses all of the factors impacting image performance, including colour and white brightness, contrast, HDR10, colour processing, as well as the capability of receiving, processing and projecting 4K content.

High dynamic range

High dynamic range presents the optimal visual experience by increasing the contrast ratio to deliver a far greater range between the darkest and lightest areas of the screen. It gives images more depth and allows you to see incredible detail that’s previously not been possible. But that’s not all; it enriches colours which makes images feel more natural yet intense, and ultimately, more immersive. With HDR support, you can now take advantage of the latest HDR content available.

High Colour Light Output

White brightness alone cannot bring the true colours you see everyday to life. That’s why the 3LCD technology found in Epson’s projectors delivers an equally high White and Colour Light Output (CLO). Why settle for a dull, washed out and lifeless screen? Experience vivid and lifelike images with Epson’s projectors.

3LCD technology – no rainbow effect

Avoid the rainbow effect with Epson’s projectors that use three individual LCD chips to simultaneously project red, green, and blue light.

In contrast, projectors with 1-chip DLP technology use a rotating wheel to project colours sequentially. Instead of a crisp edge, some viewers can experience the rainbow effect – a distracting and unnatural colour fringe.

Ultra-wide colour gamut

The ultra-wide colour gamut increases the range of lifelike colour, while the high contrast ratio delivers deep blacks for defined detail in the shadows.

Smoother fast-moving action

Even in the fastest action scenes frame interpolation and Detail Enhancement ensure motion pictures are sharp and smooth. Reducing motion blur in fast-moving scenes, frame interpolation technology inserts new frames between the original ones. As a result, blurring is suppressed and moving images look much smoother and sharper.

Flexible positioning and features for a true cinema experience at home

Looking for flexibility when it comes to installation? Ours is quick and simple thanks to a premium optical zoom ratio, and lens shift capabilities: up to ±96.3 percent on the vertical axis and up to ±47.1 percent on the horizontal axis. What’s more, the motorised zoom, focus and lens shift can store up to 10 different positions, letting you easily switch between different aspect ratios at the touch of a button. The high-quality optical zoom also makes it possible to use shorter cables, keeping any possible signal degradation to a minimum. In addition, this projector can be calibrated to professional ISF standards for greater control.

Enjoy up to seven years of entertainment

With up to 5,000 hours lifetime on the lamps, you could watch a movie every day for the next seven years without having to replace them. Epson projectors are known for their reliability, so you don’t have to worry about missing a minute of your favourite film, game or programme.

Technology

Projection System 3LCD Technology, RGB liquid crystal shutter
LCD Panel 0.74 inch with MLA (D9)


Color Light Output 2,400 Lumen
White Light Output 2,400 Lumen
Resolution 4K PRO-UHD, 16:9
High Definition 4K enhancement
Aspect Ratio 16:9
Contrast Ratio 200,000 : 1
Light source Lamp
Lamp UHE, 250 W, 3,500 h durability, 5,000 h durability (economy mode)
Keystone Correction Manual vertical: ± 30 °
Colour Video Processing 10 Bits
2D/3D Frequency Image 240 Hz / 480 Hz
2D Vertical Refresh Rate 192 Hz – 240 Hz
3D Vertical Refresh Rate 400 Hz – 480 Hz
Colour Reproduction Upto 1.07 billion colours

Optical

Throw Ratio 1.35 – 2.84:1
Zoom Motorized, Factor: 2.1
Lens Optical
Lens Shift Motorized – Vertical ± 96.3 %, horizontal ± 47.1 %
Lens position memory 10 positions
Screen Size 50 inches – 300 inches
Projection Distance Wide/Tele 3 m – 6.3 m ( 100 inch screen)
Projection Lens F Number 2 – 3
Projection Lens Focal Length 22.5 mm – 46.7 mm
Projection Lens Focus Motorized

Connectivity

Interfaces USB 2.0 Type A, USB 2.0 Type B (Service Only), RS-232C, Wireless Network (optional), Trigger out, VGA in, HDMI in (2x), HDMI (HDCP 2.2), Wired Network
Epson iProjection App Ad-Hoc / Infrastructure

Advanced Features

Security Kensington lock, Wireless LAN security
3D Active
2D Colour Modes Dynamic, Natural, Cinema, Digital Cinema, Bright Cinema
3D Colour Modes 3D Dynamic, 3D Cinema
3D Supported formats Side by side, Top and bottom
Other features 3D depth adjustment, 4K enhancement, DCI colour gamut, Epson Cinema Filter, Epson Super White, Frame interpolation, Lens position memory, Super resolution, Wireless LAN capable
Video Color Modes Cinema, Dynamic, Natural, Bright Cinema
Projector control via: AMX, Crestron, Control4

General

Power consumption 355 Watt, 271 Watt (economy), 0.2 Watt (standby), On mode power consumption as defined in JBMS-84 314 Watt
Supply Voltage AC 100 V – 240 V, 50 Hz – 60 Hz
Product dimensions 520‎ x 450 x 193 mm (Width x Depth x Height)
Product weight 11.2 kg
Noise Level Normal: 31 dB (A) – Economy: 20 dB (A)
Supported Temperature Operation 5° C – 35° C, Storage -10° C – 60° C
Supported Humidity Storage 10% – 90%
If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.

If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.

Options 3D active shutter glasses, MB22 ceiling mount, Wireless LAN unit
What’s in the box HDMI Cable Clamp, Main unit, Power cable, Remote control with background light incl. batteries, User’s Manual Set
Room Type / Application Gaming, Home Cinema, Sports, Streaming, TV & Box sets
Positioning Ceiling Mounted, Desktop
Colour White
